LV-Schaltanlage

26. Juni 2026Niederspannungsprodukt 8970

Verfügbare Zertifizierungen CE / UL Die Verfügbarkeit hängt vom Modell und der Konfiguration ab.

Übersicht

LV Switchgear, also known as UL 1558 Low Voltage Switchgear, is a key low-voltage power distribution product used for receiving, distributing, controlling, and protecting electrical energy in low-voltage systems. It is commonly installed on the low-voltage side of transformers and serves as the primary distribution equipment for downstream switchboards, panelboards, motor control systems, lighting panels, power equipment, HVAC systems, pumps, and other electrical loads.

Produktvorteile

Designed for High-Reliability Low-Voltage DistributionLV Switchgear is suitable for primary low-voltage power distribution systems where reliability and safety are critical.

UL 1558 and ANSI C37.20.1 Oriented DesignThe switchgear can be designed according to UL 1558 and ANSI C37.

Withdrawable Air Circuit Breaker ConfigurationThe product can be equipped with UL1066 low-voltage air circuit breakers.

Strong Metal-Enclosed Frame StructureThe switchgear adopts a rigid metal-enclosed frame structure.

Typische Spezifikationen

Standard Reference	UL 1558, ANSI C37.20.1
Circuit Breaker Type	UL1066 Air Circuit Breaker, ACB
Breaker Installation	Withdrawable type available
Nennstrom	Project-based configuration; high-current busbar options available
Short-Circuit / Bus Withstand	Up to 100kA available according to project design
Installation	Indoor electrical room, power distribution center, substation, industrial facility

Nur typische Konfiguration. Die endgültigen Nennleistungen werden anhand der Projektanforderungen bestätigt.

Anwendungen

LV Switchgear / UL 1558 Low Voltage Switchgear is widely used in low-voltage power distribution systems that require high reliability, high current capacity, and safe operation. It is typically installed after a transformer and acts as the main low-voltage distribution center for electrical loads.
