RCCB SVL1M-63

Spezifikation:

Tripping Current Range:

Overall and Installation Dimension (mm)

Circuit Diagram

NDB1L-32
2024年7月8日 733
NDB1L-32 is a compact RCBO for low-voltage terminal circuits. It provides overload, short-circuit and residual-current protection while allowing neutral-pole switching in a space-saving 1P+N format. Typical configuration only. Final ratings are co...
Details anzeigen
NDQ3HP
26. Mai 2023 1299
1、Application The NDQ3HP bypass automatic transfer switching equipment applies to the automatic transfer between two-way power supplies in the emergency power supply system with the AC rated working voltage of 415V and below, rated frequency of 5...
Details anzeigen
NDQ5W-1600
26. Mai 2023 1271
1. Applicable Scope and Purpose The NDQ5W-1600 automatic transfer switching equipment can be applied to the power distribution system with the AC 50Hz/60Hz, the rated working current of 200A~1600A, the rated insulation voltage of 1000 V, the rated...
Details anzeigen
NDM2-800
29. Mai 2023 1016
1. Applicable Scope and Purpose of Circuit Breaker The NDM2-800 molded case circuit breaker (hereinafter referred to as circuit breaker) applies to infrequent switching of circuits with the AC 50Hz, the working voltage of AC690V and working curr...
Details anzeigen

Electrical Features
Mode	Electromagnetic
Type (wave form of the earth leakage sensed)	B
Rated Current In	25, 40, 63A
Poles	2P, 4P
Rated Voltage Ue	2P 240V~, 4P 415V~
Insulation Voltage Ui	500V
Rated Frequency	50/60Hz
Rated Residual Operation Current (I△n)	30mA
Rated Residual Operating Current (I△dc)	6mA
Rated Residual Making & Breaking Capacity (I△m)	500A (In≤40A), 10In (In＞40A)
Short-circuit Current Inc = I△c	10000A
SCPD Fuse
Break Time Under I△n	≤0.1s
Rated Impulse Withstand Voltage (1.5/50) Uimp	4000V
Dielectric Test Voltage at ind.Freq. for 1min	2.5kV
Electrical Life	2000 Cycles
Mechanical Life	4000 Cycles

Installation
Contact Position Indicator	Yes
Protection Degree	IP20
Ambient Temperature (with daily average≤35℃)	-25℃~+35℃
Storage Temperature	-25℃~+70℃
Terminal Connection Type	Cable/Pin-type Busbar/U-type Busbar
Terminal Size top/bottom for Cable	35mm² 18~3AWG
Terminal Size top/bottom for Busbar	35mm² 18~3AWG
Tightening Torque	2.5Nm 22In-lbs
Mounting	On DIN Rail EN60715(35mm) by means of fast clip device
Connection	Power Supply in Both Directions

Lagging Angle	I△n＞0.01A	I△n≤0.01A
0°	0.35I△n ≤ I△ ≤ 1.4I△n	0.35I△n ≤ I△ ≤ 2I△n
90°	0.25I△n ≤ I△ ≤ 1.4I△n	0.25I△n ≤ I△ ≤ 2I△n
135°	0.11I△n ≤ I△ ≤ 1.4I△n	0.11I△n ≤ I△ ≤ 2I△n

Alternative Current Sensitive	Pulsating Direct Current Sensitive	Surge Current Proof
B Class Tripping is ensured for sinusoidal AC residual currents pulsed DC residual current, alternating residual sinusoidal currents up to 1000Hz, pulsating direct residual currents and for smooth direct residual currents, whether applied suddenly or increasing slowly.	They react to AC and pulsating DC fault current which reach 0 or almost 0 within one time period of the mains frequency.	RCCB’s surge capacity. Not tripping at standardized 8/20 us surge-current waves acc.to VDE 0432 Part 2 with surge current values of up to 250A.
